Rare Parts Tie Rod End 1931-1933 Buick Series 50 1934-1936 Auburn 8-851 8-852 850Y 850X 26428

Rare Parts Tie Rod End
#26428 or RP26428
1931-1933 Buick Series 50
1934-1936 Auburn
(See extended description below for full vehicle application information and placement)

Tie Rod End is grease-able
Includes hardware

Specifications:
Rod Thread    3/4-16
Bar Size    1.018
RH/LH    LH
Male or Female    Female
Large Dia. Taper    0.710
Small Dia. Taper    0.640
Stud Thread Size    1/2-20
Length Ctr. Stud to End    2.600
Config.    Straight
Greaseable    Yes
Dust Boot Included    Yes
Package Contents    1 Tie Rod End, 1 Dust Boot, 1 Castle Nut, 1 Cotter Pin, 1 Clamp, 1 Bolt, 1 Lock Washer, 1 Nut, 1 Grease Fitting

FITS:
1931; Buick; Series 50 Front Right
1932; Buick; Series 50 Front Right
1933; Buick; Series 50 To Frame #2673137 Front Right
1934; Auburn; Model 850Y 3/4"-16 x 2.6" Long Left
1934; Auburn; Model 850X 3/4"-16 x 2.6" Long Left
1935; Auburn; Model 8-851 3/4"-16 x 2.6" Long Left
1936; Auburn; Model 8-852 3/4"-16 x 2.6" Long Left
