Competition Cams - Xtreme Energy Camshaft

P/N 32-250-4

Fits: 1970-1982 Ford 351C, 351M, 400 V8 Engines

You Are Purchasing The Camshaft Only, All Other Part Numbers Listed Below Are For Reference Purposes Only

Cam Style: Hydraulic flat tappet
Basic Operating RPM Range: 2,300-6,500
Intake Duration at 050 inch Lift: 240
Exhaust Duration at 050 inch Lift: 246
Duration at 050 inch Lift: 240 int./246 exh.
Advertised Intake Duration: 284
Advertised Exhaust Duration: 296
Advertised Duration: 284 int./296 exh.
Intake Valve Lift with Factory Rocker Arm Ratio: 0.584 in.
Exhaust Valve Lift with Factory Rocker Arm Ratio: 0.588 in.
Valve Lift with Factory Rocker Arm Ratio: 0.584 int./0.588 exh.
Lobe Separation (degrees): 110
Computer-Controlled Compatible: No
Grind Number: XE284H
Valve Springs Required: Yes

Quantity: Sold individually.

Features:

  • Produces Better Throttle Response
  • Produces Top Engine Horsepower
  • Delivers Increased Engine Vacuum
  • 1 Year Limited Warranty
Recommended Components
Component Part Number
Lifter Kit 832-16 / 862-16 [37]
Timing Set 2121 / 3121
Rocker Arms 1411-16 [1] / 1330-16 [1]
Push Rods 7502-16 [8] / 7945-16
Valve Springs 924-16 [2] / 930-16 [2]
Steel Retainers 741-16 / 732-16
Valve Locks 611-16 [71]
Valve Seals 503-16 [2]
Camshaft Break-In Lube 159
Installation Notes (These notes apply to the above recommended components with the trailing installation note numbers)
Note Description
1 [1] Requires screw-in studs & guide plates.
2 [2] Requires machining on cylinder heads.
7 [7] Stock springs cannot be used.
8 [8] Fits only certain years.
37 [37] Adjustable valve train required.
71 [71] For engines with multi-groove valves, use part #624-16 locks. CAN NOT be used with lash caps.

1970 1971 1972 1973 1974 1975 1976 1977 1978 1979 1980 1981 1982
